VTI Instruments - ExLab Full Featured, Turn-Key Data Acquisition Software
- Intuitive, icon-based setup and control
- Spreadsheet-style channel configuration
- Snapshot display with data export
- Independent sampling rates for each instrument
- Real-time online graphical data analysis
- Client / server architecture with multiple displays
- Synchronization of different data sources
- Detect/process events for close-loop control
- Post-acquisition analysis methods and data playback
- Easily create Virtual/Calculated channels based on physical channel data
EXLab-based systems are a combination of robust, turnkey software and precision instrumentation designed to solve your toughest problems in verifying designs of electro-mechanical products. Combining analog, digital, and counter measurements in a single system reduces integration and startup time. If your measurements include acoustic, vibration, temperature, pressure, strain, voltage, digital states, rpm or other transducer-based parameters, and you’re feeling the pressure of time, then an EXLab-based system is the right solution for you.
- High Speed Data Acquisition
- General Purpose Data Logging
- HALT / HASS Product Evaluation
- Engine Test Cell Acquisition
- Structural Testing
- Process and Plant Monitoring
- Performance and Event Monitoring
Accurate Data, Powerful Display and Analysis
EXLab Data Acquisition Software Suite delivers reliable data, first time, every time ensuring critical test data is never compromised. This intuitive icon-based tool simplifies instrument configuration, acquisition and data display without sacrificing functionality or performance.
A wide range of flexible displays, channel groupings, and runtime alarms can be mixed and matched for clearly identifiable data management and analysis, providing a real-time picture of test results and conditions. Extensive post processing tools, including FFT and power spectral density analysis, cursor and marker control, seamless zooming, report capture, and open data export capability enables complete acquisition, control and analysis in one easy to use package.
Application Specific Capabilities
Whether performing dynamic measurement, structural fatigue/strain measurements, or precision temperature measurements, EXLab offers full featured capabilities for each application space.
More Product Information
- Highest resolution – 12 bits all the time
- More capability – integrates multiple instruments into one
- Comprehensive probe support – supports over 30 probes in 9 categories
- MAUI with OneTouch user interface for intuitive and efficient operation
- Eight ports of 8 I/O bits each
- High current capability for control of external relays, 300 mA sink
- Simulate and receive digital data at up to 2 MHz sample rates
- Selectable output voltages range from 3.3 V to 60 V
- Setup outputs and scan inputs as part of EX1200 measurement sequencing engine
The EMX-2500 is a Gigabit Ethernet LXI Controller for the EMX Series of PXIe Instruments.
- Combine up to 12 fail-safe building blocks, dual SPDT, SP4T, SP6T, or transfer switch in a compact 1U footprint
- Front “pluggable” relays facilitate field maintenance
- Embedded web interface provides interactive utility to monitor and control relays from anywhere in the world
- Flexible API supports IVI and Linux development environments minimizing software investment
- LXI Trigger Event implementation provides seamless test synchronization with external devices
- Store up to 128 relay state configurations for quick recall, including an automatic power up state
- Define exclude lists to avoid setting an undesirable configuration
- Relay odometer tracks closures to facilitate preventative maintenance
-
Automatic calibration of instruments
-
In line with ISO17025 and other metrology standards
-
Automated optical readout module for multimeters
-
Unlimited custom instruments and procedures
- 24-bit, delta-sigma ADC, simultaneous sampling
- Programmable Sample Rate up to 128kSPS
- Full, Half & Quarter Bridge with 120Ω, 350Ω & 1kΩ bridge completion
- Voltage Excitation: 0.5V to 10V
- Current Excitation: 0.46mA
- 2-Wire & 4-Wire Ohms/RTD
- Bridge Zero Balancing
- Built-In-Self-Test (BIST)
- Strain Lead Wire Calibration
- Shunt Calibration: 50kΩ, 100kΩ & External provided by User
- TEDS Support
- LXI Ethernet Interface
- IEEE-1588 Synchronization
- Power over Ethernet (PoE) or 10–50 V DC input
- Built-in Parallel Data Streaming
- Full-featured Embedded Web Interface
- Compact 1U Half-rack Form Factor
The SMP6xxx product family is made up of the SMP6001, SMP6002, SMP6004, SMP6005, SMP6006, SMP6101, SMP6102, SMP6103, SMP6122, SMP6144, SMP6202, SMP6301 (pictured), SMP6301T, and SM6306.
The APEX Turbine Data System (DS) is the next generation of data acquisition, control, setup, and online analysis. It reliably acquires time-synchronized data from a network of digitizers, regardless of sample rate or sensor type.
-
Complete Test Solutions
-
Complete test solutions for emissions and immunity compliance testing of AC and DC powered products
-
-
Single & Three Phase Operation
-
Offers flexibility
-
-
Direct PC Bus Access
-
Provides high sampling rate and resolution for accurate measurements and high speed data transfers
-
-
PC based harmonic & flicker testing
-
provides real-time full color data display updates and continuous PASS/FAIL monitoring.
-
-
Supports Global Standards
-
Supports European and Japanese standards
-
-
Easy To Use Interface
-
Provides IEC test setup, data analysis, display, MS Word test reports, and data files are generated in MS Excel format
-
-
High resolution
-
Data storage to disk in for post-acquisition analysis and reporting
-
-
Single Step
-
Single Step and Fast Forward replay of recorded test data at 200 mSec
-
VTI Instruments
VTI Instruments, an AMETEK Programmable Power brand, provides products and systems which are used to monitor and record data that characterizes the physical integrity and performance of aircraft, engines, and other large structures, as well as automate the functional testing of complex electronic systems. VTI Instruments is recognized as an industry leader with a reputation of providing reliable data, first time, every time. A sustained focus on innovation and technology enables customers to optimize their capital investment through product longevity, while ensuring unmatched measurement integrity and data reliability.
VTI Instruments has customers in over 30 different countries and in a wide variety of industries including aerospace, defense, power generation, automotive and consumer electronics.
