The I3 and I3S Inline Controllers provide overdrive strobe and continuous operation to lights from a small package when larger, more versatile external controllers are not necessary.
-
Switching between continuous-on, gating on/off and strobe overdrive is seamless. The I3 and I3S employ Ai’s exclusive Adaptive OverdriveTM that optimizes strobe power regardless of input Pulse Width.
-
The I3 is a default-on device on power-up, whereas the I3S is a default-off device, requiring a trigger to illuminate.
-
All ICS models employ reverse input polarity protection.
-
Provides continuous-on and DC gating on/off control as well as 0-10 volt analog dimming. 30 uSec response time.
-
A wash down version of all ICS drivers is provided automatically with any wash down light to which it is attached.
-
0 – 100% Intensity Control with optional DCS-MP, purchased separately, will provide manual intensity control via an external potentiometer.
Advanced Illumination - ICS I3 & I3S Inline Controllers
General Specs
Controller Style
Inline Control System (Cable Inline, Permanently Affixed)
Operating Modes
Pulse (Overdrive Strobe), Gated Continuous, Continuous
Input Connection
Flying Tinned Leads or Optional A-coded 5-pin Male M12 Connector
Input Supply Requirements
24V DC Nominal, 1.25A Recommended
21V Min - 30V Max; Power Inputs Reverse-Polarity Protected
21V Min - 30V Max; Power Inputs Reverse-Polarity Protected
Output Channels
1 Inline Channel
Output Power
Continuous: 25W Max*
Pulsed: 125W Peak Max*
Pulsed: 125W Peak Max*
Output Current
Continuous: 1.25A Max*
Pulsed: 8A Max* (Load Dependent)
Pulsed: 8A Max* (Load Dependent)
Output Voltage
Vin - 1V
Trigger Signal
Single PNP, Active High, TTL Compatible
2.5V Min - 30V Max, <=5mA
2.5V Min - 30V Max, <=5mA
Trigger Protection
Protected up to 30V
Trigger Delay
20μs + 10μs LED rise-time
Trigger Frequency Limit
2KHz *Requires Duty Cycle ≤ 1% beyond 1KHz
Pulse Width Range
30μs - ∞
Duty Cycle Range
<5% up to 5ms
<10% up to 10ms
≥ 10% past 10ms
<10% up to 10ms
≥ 10% past 10ms
Analog Dimming
0V - 10V (0% - 100%); <=5mA
Operating Temperature Range
0°C to +40°C
Storage Temperature Range
-25°C to +85°C
IP Rating
Non-sealed: Not Rated
Sealed: IP67
Sealed: IP67
Dimensions
Non-sealed: 3.73" x 0.82" DIA (94.6mm x 20.6mm DIA)
Sealed: 5.06" x 0.82 DIA (128.7mm x 20.6mm DIA)
Sealed: 5.06" x 0.82 DIA (128.7mm x 20.6mm DIA)
Weight
Approx. 0.106lb (48g)
Mounting
N/A (In-line)
Case Material
Polycarbonate
Warranty
5 Years
Compliance
CE, RoHS
*Values shown are based on controller component limitations. Actual limitations will vary depending on the limits set for the connected light head. These limits are hardcoded into each in-line controller to prevent LED failure from occurring when driven beyond the light's acceptable range.
Mechanical Specs
Wiring Diagrams
Electrical Specs
Additional Specs
Document
Document
