VTI Instruments - EX1200 Series LXI Mainframes
The LXI mainframes family includes 2-slot, half-rack LXI switching and data acquisition mainframes (EX1202/EX1262), 16-slot, 3U LXI switching and data acquisition mainframes (EX1208A and EX1208B, pictured), and 6-slot, 1U LXI switching and data acquisition mainframes (EX1206A).
The EX1200 family is the highest density switch and data acquisition instrument on the market with the ability to mix low-level, power, and RF switch modules in a single mainframe. This scalable family of products is designed to leverage capital investments in one common hardware and software platform that can be used in development, manufacturing, and field service. Mix and match a variety of modules to build a comprehensive signal switching subsystem that can be supplemented with precision analog and digital I/O modules.
DATA ACQUISITION
When installed with the optional 6.5 digit DMM, the EX1200 family can be configured as a cost-effective, high-density, scanning measurement and control instrument capable of acquiring data from thermocouples, RTDs, thermistors, and voltage/current sensors at rates up to 1000 samples per second. Plug-in switch/multiplexer modules are used to expand the number of channels that can be scanned in a single system. Additional plug-in modules extend the capabilities of this instrument for data acquisition by adding precision analog and digital outputs for controlling external devices, as well source/tach for measurements on rotating machinery.
SWITCH AND CONTROL
The award winning EX1200 series offers nearly double the available working space and increased channel count capacity to ensure the highest degree of signal integrity in the same vertical footprint as PXI. For lower density switching applications, VTI also offers a comprehensive family of high-performance PXI Express switch modules.
CABLING AND CONNECTORS
The performance of a switch system goes beyond just the relays and the switch card PCB. Everything in the signal path, including the cabling and connectors from the DUT and to the measurement instruments, can add noise and degrade the signal. VTI optimizes the system-level performance by providing easy to use connectivity options for all the EX1200 products that minimize signal loss.
LXI Instruments & Hardware
LXI instruments range from LXI modules that plug into a chassis to standalone instruments that have dedicated LXI and hardware trigger bus connections. These instruments can be configured to measure many types of variables to precise values. Some of these instruments also incorporate 6.5-digit DMMs as well as user-programmable digital alarm circuits.
|
EX1202/EX1262 |
2-slot, Half-rack LXI Switching and Data Acquisition Mainframes |
|---|---|
|
EX1208A |
16-slot, 3U LXI Switching and Data Acquisition Mainframe |
|
EX1208B |
16-slot, 3U LXI Switching and Data Acquisition Mainframe |
|
EX1206A |
6-slot, 1U LXI Switching and Data Acquisition Mainframes |
More Product Information
The SMP5xxx product family is made up of the SMP5001 through SMP5005 general purpose relays.
- Up to 96 differential channels per full rack mainframe
- Constantly monitor input signals for fault conditions
- Flexible configurations for detecting edges, out-of-bounds conditions and measuring pulse widths
- Inputs can be masked, inverted, and combined to produce interrupts
- Can be used as a time stamp module and as a digital I/O
- Programmable debounce circuitry prevents erroneous readings
- 10 V and 100 V input ranges
- On-board memory stores events with IEEE 1588 timestamps
- Synchronize reading of input states with other scanned analog channels
- Eight ports of 8 I/O bits each
- High current capability for control of external relays, 300 mA sink
- Simulate and receive digital data at up to 2 MHz sample rates
- Selectable output voltages range from 3.3 V to 60 V
- Setup outputs and scan inputs as part of EX1200 measurement sequencing engine
The EMX-2500 is a Gigabit Ethernet LXI Controller for the EMX Series of PXIe Instruments.
- High power density in 1U / 2U / 4U / 14U chassis up to 18kVA
- Intuitive touch panel control
- Innovative iX2™ current doubling technology
- Multi-language display for global operation
- Auto paralleling for higher power
- Single phase 1U models and 1 or 3 phase selectable 2U / 4U / 14U models
- Complete avionic test suites (optional)
- ATE version available in 1U, 2U and 4U models
- Standard LXI LAN, USB and RS232, optional GPIB
- Legacy CSW5550 Emulation on the AST6003A1 Model
The SM7000 Series microwave switching modules are members of the VXI Technology SMIPII™ family. They offer a modular design allowing custom switching configurations to be easily assembled and modified in the field.
The SM7000 is a single-wide, C-size VXI module, which can support up to six different microwave switches including: a dual SPDT; SP3T through SP6T; transfer switches and passthrough adapters that allow the module to control up to eight externally mounted relays each.
- High-density, compact (1U) precision data acquisition instruments
- LXI™ LAN connectivity
- Fully integrated signal conditioning maximizes performance and accuracy
- Easily integrate thermocouples, voltages, RTDs, thermistors, frequency, strain and pressure on an per-channel basis
- Distributed, synchronized measurements over the wire
- Scalable architecture easily expands from tens to thousands of channels
- DC version available for test cells requiring closer proximity to test article
- End-to-end self-calibration ensures optimum runtime performance
- Web-based access for monitoring and control
- Exlab turnkey software for simplified setup, control and data display
Flexibility
- Ideal for a wide range of applications such as RF, mm-Wave and sub-THz characterization, FA, DWC, MEMS, optoelectronic tests and WL
- Re-configurable and upgradable as requirements grow
- Minimizes setup times with no loss in performance or accuracy
- Seamless integration of various measurement instruments
Stability
- Solid station frame
- Built-in vibration-isolation solution for superior vibration attenuation
- Rigid microscope bridge
- Compact and rigid mechanical design
- Highly accurate measurement results
- Incorporates best-known methods
Ease of Use
- Ergonomic and straightforward design for comfortable and easy operation
- Low-profile design
- Simple microscope operation
- Quick and ergonomic change of DUT through pull-out stage
- Minimize training efforts
- Fast time to data
- Convenient operation
- General purpose switching up to 300 V / 2 A
- Easy to use end-to-end path level switching for simplified programming
- Best bandwidth and crosstalk performance in its class
- Can be mixed and matched to create application specific configurations
- Ideal for general purpose switching of up to 300 V (AC/DC) or 2 A
- Can be used to switch a common point to either power or ground (Form C)
- Connect together using external wiring for flexible switch design
- Easy to use configuration software facilitates end-to-end path-level switching for simplified programming
