The LL137 Series provides a focused line of illumination in a passively cooled design.
-
Provides a medium intensity level of 280kLux (working distance of 75mm)
-
Pre-engineered for expandability in 6” (152mm) increments up to 96” (2.44m).
-
Available intensity control provides illuminance adjustability for every 6″ increment via a 0 – 10v input
-
Note: If only looking for white illumination, our LL167 Series provides a 74% brighter beam in a similar package.
Advanced Illumination - LL137 Series Medium Intensity Line Lights
General Specs
Group 1 (Low-Risk) Applicable Wavelengths: 455, 530, 625, WHI, RGB
Mechanical Specs
Optical Specs
Electrical Specs
Control Specs
Part No Key
More Product Information
-
Pre-Engineered Scalability Enables Customized Emitting Lengths in 2″ Increments to 20″
-
Intense, Diffuse Lighting with 226 kLux at Emitting Surface
-
Multiple Available Wavelengths, Including Visible Monochromatics, Infrared, and White
-
Available Washdown Option for Difficult Environments
-
Can be Applied in Backlighting or Diffuse Front Lighting Geometries
-
Network Enabled Frequency Distribution Amplifier
-
Dual Frequency Inputs with Auto Failover
-
Low Phase Noise Reference Frequency Outputs
-
Programmable per channel amplitude
-
1U 19” rack mount
-
Redundant Hot Swappable Power Supplies
-
Multi-purpose SIGMA instrument integration kit
-
Shorter cabling and universal chuck connection
-
Triax probe with protected guard
-
Triax design for low-leakage measurements up to 3 kV
-
Special chuck surface coating
-
High-isolation ready
-
Arcing protection
-
Shield Enclosure with interlock
-
Advanced grounding concept
-
Backward Compatible with L Series
-
Function and bus compatible with the California Instruments L Series
-
-
Three phase and Single phase modes
-
Ideally suited for avionics and defense applications
-
-
3 KVA to 18 KVA Power Levels
-
Match power source and cost to application requirements
-
-
Transient Programming
-
Test products for susceptibility to AC line disturbances
-
-
Built-in Measurements
-
Performs voltage, current, and power measurements
-
-
Advanced Features
-
Arbitrary waveform generation, harmonic analysis, GPIB interface are some of the available options
-
-
Interface
-
Standard USB & RS232C interface.
-
Optional GPIB & LAN available
-
-
CE Marked (400V input model ONLY)
-
Safe, reliable, and consistent operation
-
Key Features Lx Series
-
Backward Compatible
-
Compatible with HP6834B & iL Series AC Sources Function & bus compatible with the Agilent HP6834B & California Instruments iL Series
-
-
Three phase and Single phase modes
-
Ideally suited for avionics and defense applications
-
-
3 KVA to 18 KVA Power Levels
-
Match power source and cost to application requirements
-
-
Arbitrary Waveform Generator
-
Test products for harmonics susceptibility
-
-
Built-in Power Analyzer
-
Performs voltage and load current harmonic analysis and waveform acquisition
-
-
Standard IEEE-488, USB & RS232
-
Remote control interface for ATE system integration include
-
-
The SL223 is characterized as a MicroBrite™ Spot/Coaxial Light and is designed primarily to replace fiber optic light sources in coaxial lensing applications.
-
Optional couplers are available for use with Dolan-Jenner, Fostec, and Moritex fiber bundles.
-
The SL223 is also designed for general lighting purposes where a very intense, miniaturized light source is required. General purpose spot lights may be used to create both dark field and bright field affects, depending on how they are deployed during the inspection.
-
The spot light is designed to provide 8.1kLux at a working distance of 4” (100mm) and is available in a very wide range of wavelengths from UV to IR.
-
The SL223 is rated for IP65 washdown capability.
-
The LL137 Series provides a focused line of illumination in a passively cooled design.
-
Provides a medium intensity level of 280kLux (working distance of 75mm)
-
Pre-engineered for expandability in 6” (152mm) increments up to 96” (2.44m).
-
Available intensity control provides illuminance adjustability for every 6″ increment via a 0 – 10v input
-
Note: If only looking for white illumination, our LL167 Series provides a 74% brighter beam in a similar package.
-
Advanced MicroVac chuck surface for minimum contact resistance between wafer and chuck
-
Safety-rated interlock system for high-power testing (meets EN 60947-5-1, EN 60204-1)
-
Supports fully automated testing up to 10kV by eliminating arcing point
-
Full wafer access via locking roll-out stage
-
On-wafer power device characterization up to 10,000 V DC / 600 A
-
Coaxial, triaxial, and pin jack feed-troughs available
-
Convenient instrument connection kits
-
Load/unload wafer to hot/cold chuck (-60° C to +300° C)
-
Up to 15% faster transition times than other systems in the market
-
The SL162 is characterized as a High Intensity Spot/Coaxial Light and is designed primarily to replace fiber optic light sources in coaxial lensing applications.
-
Optional couplers are available for use with Dolan-Jenner, Fostec, and Moritex fiber bundles.
-
The spot light is designed with sufficient thermal management to provide 33kLux at a working distance of 4” (100mm).
-
A very wide range of wavelengths from UV to IR are available.
-
Our classic LL163 Line Lights are suitable for low intensity, low speed line scan applications.
-
These line lights are well established and have proven reliability.
-
Provides a intensity level of 24kLux (working distance of 25mm).
-
Available in 7 wavelengths including 395nm (UV) and 880nm (IR).
-
Pre-engineered for expandability in 1.5” (38.1mm) increments up to 81” (2.06m).
-
LL163 derivatives include LL2912 (3”), LL3024 (6”) and LL3148 (12”) (which represent legacy part numbers)
Advanced Illumination
